1600-5 Multifunctional Automatic Hydraulic Flanging Machine
Ⅰ. Equipment Introduction (Purpose, Main Functions and Features)
1. Equipment functions: flanging, pulling, upper folding, punching, and flaring; forming configuration saving function, only need to call out the program when changing the workpiece (greatly reducing the difficulty of debugging, saving debugging time, and enhancing the consistency of production products).
2. The spindle is equipped with a high-power servo motor and a planetary reducer to improve the punching efficiency and the accuracy of indexing.
3. This type of machine with an annual output of about 100 units can provide strong technical support.
4. The support device adopts a cylinder support, which has strong support force and small radial swing when the workpiece rotates.
5. The flange width adjustment adopts a step-type module, the flanging width is more stable, and the adjustment type saves time.
6. The corner-type star reducer is adopted to make the machine lower and more convenient to operate.
Ⅱ. Design and manufacturing standards (This equipment is customized according to customer requirements and negotiated by both parties)
1. Machine layout: vertical
2. Processing scope: flange forming of vibration screen frame, indexing punching work.
3. Processing technology: manual loading----machine forming----manual unloading
4. Mold type: hydraulic internal expansion mode.
5. Operation interface: touch screen
6. Control mode: PLC
7. Working environment: working environment temperature -15° to 40°, relative humidity does not exceed 85%, away from strong electromagnetic interference and strong vibration.
| Power supply type: | AC 380V (customizable according to different countries) three-phase four-wire |
| Total equipment power: | about 15kw |
| Equipment specifications: | about 3300x2100x1900 (MM) |
| Processing product diameter: | 400-1600MM |
| Processing product thickness: | 2-6MM (carbon steel) ,2-4MM (stainless steel) |
| Processing product height: | blank size within 100-1600MM |
| Flanging width: | 20-60MM |
| Configuration mold specifications: | 400--1600mm |
| Punching accuracy range: | ± 1.0MM |
| Punching diameter: | 5-16MM |
| Equipment weight: | 4.9 tons |
1. Non-standard customization: meet personalized technical requirements.
2. Samples and drawings: professional R&D team design.
3. Flexible payment: T/T, LC, international bank.
4. Video factory inspection: can be scheduled.
5.Experienced professional sales service team.
6. Visual production process.
