The CNC dieless flanging punching machine for large circular cone fan air inlet has the following characteristics.
Equipment structure:
Fuselage structure: The fuselage is usually welded with high-strength steel, with sufficient rigidity and stability to withstand the large forces generated during the processing of large circular cones. In order to facilitate operation and maintenance, the design of the fuselage will take into account the principles of ergonomics, so that operators can easily operate and monitor the operating status of the equipment.
Transmission system: Generally equipped with a high-precision servo motor or hydraulic system as the power source, the power is transmitted to the actuator of flanging and punching through the transmission device. The servo motor has the advantages of fast response speed and high positioning accuracy, and can achieve precise position control; the hydraulic system has the characteristics of large output force and stable operation, which is suitable for processing large workpieces.
Flanging device: The flanging device is one of the core components of the equipment, and its structure and performance directly affect the quality and efficiency of flanging. Usually a special roller or pressure wheel structure is used to gradually squeeze and bend the edge of the air inlet during the rotation of the workpiece to achieve the flanging operation. The design of the flanging device will take into account the characteristics and thickness of different materials to ensure the effect and quality of the flanging.
Punching device: The punching device consists of a punching die and a punching power mechanism. The punching die is designed and manufactured according to different punching requirements, has high hardness and wear resistance, and can ensure the accuracy and service life of the punching. The punching power mechanism can use cylinders, hydraulic cylinders or mechanical transmission to provide sufficient punching force for the punching die to ensure that the required holes are accurately punched on the workpiece
Improve product quality: Precise flanging and punching processing can ensure the dimensional accuracy and shape accuracy of the fan inlet, and improve the quality and reliability of the product. The edge of the air inlet after flanging is flatter and smoother, which is conducive to improving the air intake efficiency of the fan and reducing noise; the position and size of the punching are accurate, which can ensure the assembly accuracy of the air inlet and other components and improve the overall performance of the fan.
Reduce production costs: Moldless processing technology reduces the production and maintenance costs of molds, while improving the utilization rate of materials and reducing the waste of raw materials. Automated processing methods reduce the need for manual operation, reduce labor costs, and can improve production efficiency and shorten production cycles, thereby reducing overall production costs.
Enhance production flexibility: The programmability of the CNC system enables the equipment to quickly switch between different processing parameters and processes to meet the processing needs of fan inlets of different models and specifications. This flexibility can meet the diverse order requirements of customers and improve the market competitiveness of enterprises.
| Origin: | Guangdong, China |
| Machine type: | cold forging machine |
| Weight (KG): | 34000 |
| Video factory inspection: | provided |
| Machine test report: | provided |
| Sales type: | general products |
| Core component warranty: | 1 year |
| Core components: | PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump |
| Warranty: | 1 year |
| Main selling point: | easy operation |
| Applicable industries: | manufacturing plants, construction projects, other |
| Showroom location: | no |
| Status: | brand new |
| Flanging material thickness: | 3-12MM (stainless steel) |
| Processing diameter: | 400-3000mm |
| Flange cylinder height: | 100-1000 (finished product) |
| Power supply type: | 380v three-phase four-wire |
| Total power: | 98kw |
| Equipment specifications (mm): | 6000x3800x4000 (length, width and height) |
| Equipment function: | hemming + punching |
| Drive mode: | CNC (servo) |
| Control mode: | CNC system |
| Programming mode: | G code programming |
1. Non-standard customization: meet personalized technical requirements.
2. Samples and drawings: professional R&D team design.
3. Flexible payment: T/T, LC, international bank.
4. Video factory inspection: can be scheduled.
5.Experienced professional sales service team.
6. Visual production process.
1. Provide circuit diagrams, maintenance manuals,full-course teaching videos and other materials required.
2. Full-time after-sales service, cooperate with customers to inspect, install and test.
3. Quick response: respond within 24 hours if there are any problems with the customers use.
Wide range of applications: It can be applied to the processing of circular cone fan inlets of various diameters and thicknesses. Whether it is a small ventilator or a large industrial fan, as long as its air inlet is in the shape of a circular cone, the equipment can be used for flanging and punching.
High processing accuracy: Due to the use of CNC technology and high-precision transmission system, the equipment can achieve high processing accuracy. The angle and depth errors of the flanging can be controlled within a small range, and the position accuracy and dimensional accuracy of the punching can also meet the assembly and use requirements of the fan inlet.
High processing efficiency: Compared with traditional manual processing or die processing methods, the processing efficiency of CNC dieless flanging punching machines is greatly improved. The equipment can continuously and automatically perform flanging and punching operations, reducing the time for manual intervention and adjustment, and can quickly complete a large number of processing tasks.
CNC technology control:
using advanced CNC technology to accurately control the entire flanging punching process. The operator can input relevant processing parameters through the CNC system, such as the angle and depth of the flanging, the position and size of the punching, etc. The system will automatically control the action of the equipment according to these parameters to ensure the accuracy and consistency of the processing.
Dieless processing technology:
Different from the traditional die flanging punching, the dieless flanging punching machine uses a specific mechanical structure and processing technology to perform flanging and punching operations on the air inlet of the circular cone fan without the need for a mold. This technology can greatly reduce the cost and time of mold production, and also improve the flexibility of processing, and can quickly adapt to the processing of air inlets of different sizes and shapes.
