The Titanium Alloy CNC Spinning Machine is an advanced metal processing equipment that combines CNC technology with spinning technology, providing efficient and accurate solutions for the processing of metal products of various complex shapes.
Titanium Alloy CNC Spinning Machine:
1. With mature CAD drawing programming software functions, the motion trajectory of the spinning wheel can be straight lines, arcs, multi-arc connecting lines and combined curves, etc. And input into the computer for standardized programming of passes.
2. The operator can input process parameters and spinning passes through the keyboard and operation panel, and can edit, store and call them at will.
3. It has the function of "copying" the core mold contour protection, that is, when adjusting the process and recording and returning the teaching, the spinning wheel will not collide with the core mold.
4. The machine tool can pause the feed speed and spindle speed in the automatic program. It is equipped with travel limit protection, software and hardware limit protection in the control system, fault detection and alarm functions.
5. Automatically detect faults of each unit when starting up, automatic diagnosis and overload protection, etc.
6. According to the user's requirements, various special shapes of parts can be spun to ensure that the workpiece surface, diameter, thinning rate and other related dimensions meet the requirements.
7. The same machine tool can complete trimming, flanging, curling, shrinking, rolling and other functions.
High-precision processing:
The advanced CNC system can accurately control the motion trajectory and pressure of the spinning wheel to ensure that the processing accuracy reaches a very high level. Whether it is thin-walled parts or complex curved surfaces, accurate forming can be achieved.
Efficient production:
The double-wheel design greatly improves the processing speed, and can process both sides of the workpiece at the same time, reducing processing time and improving production efficiency.
Versatility:
It is suitable for spinning processing of various metal materials, such as aluminum, copper, steel, etc. It can process parts of various shapes, such as cylindrical, conical, spherical, etc., to meet the needs of different industries.
Easy operation:
Equipped with an intuitive human-machine interface, the operation is simple and convenient. The operator only needs to enter the processing parameters, and the equipment can automatically complete the processing process, reducing the requirements for the operator's technical level.
High reliability:
High-quality mechanical parts and electrical components are used, and strict quality inspection and testing are carried out to ensure the reliability and stability of the equipment. Reduce equipment failure and maintenance time, and increase the service life of the equipment.
| Power supply type: | AC 380V three-phase four-wire |
| Maximum spinning product diameter (mm): | 1200 (sheet diameter) |
| Processing capacity: | heavy |
| Maximum workpiece weight (kg): | 320 |
| Spindle motor power (kW): | 19.5 |
| Number of spindles: | 3 axis |
| Spindle speed: | 10-1000 rpm |
| Stroke (X axis) (mm): | 800 mm |
| Stroke (Z axis) (mm): | 510 mm |
| Positioning accuracy (mm): | ±0.02 |
| Repeat accuracy (X/Y/Z) (mm): | ±0.02 |
| Origin: | Guangdong, China |
| Installable tool positions: | 6+6 |
| Weight (KG): | 6200 |
| Warranty: | 1 year |
| Mechanical inspection report: | provided |
| Video factory inspection: | provided |
| Core component warranty: | 1 year |
| Screw width (mm): | 30 mm |
| Feed speed: | 5 meters/minute |
| Dimensions (length*width*height): | 2800x3000x1800 (mm) |
| Brand: | Zhuosheng |
| Model number: | ZS-XY-1000-B |
| Automatic oiling system: | AC 220V 25W1 |
| CNC system: | Diens/Guge |
| Main selling point: | Multi-function |
| Type: | Cold bending machine |
| Control method: | PLC touch screen CNC |
1. Non-standard customization: meet personalized technical requirements.
2. Samples and drawings: professional R&D team design.
3. Flexible payment: T/T, LC, international bank.
4. Video factory inspection: can be scheduled.
5.Experienced professional sales service team.
6. Visual production process.
1. Provide circuit diagrams, maintenance manuals,full-course teaching videos and other materials required.
2. Full-time after-sales service, cooperate with customers to inspect, install and test.
3. Quick response: respond within 24 hours if there are any problems with the customers use.
We are grateful for your support and trust along the way. We are honored by your cooperation every time, and we will live up to your trust and provide you with a more excellent experience.
We can also help you with all your equipment packaging needs. Whether you need split packaging, certified materials or general packaging advice, our team of experts can help you. We understand that every business is different, so we tailor our services to your needs. Our goal is to make your life easier by meeting all your packaging needs so that you can focus on running your business.
As a professional mechanical equipment manufacturer, our company is a private technology innovation enterprise integrating independent research and development, design and manufacturing, installation and commissioning, and training.
Our R&D team has 10 people, whose members cover multiple professional fields such as mechanical engineering, electronic information, and materials science, and have the ability to deal with different technical problems.
Our equipment is widely used in aerospace, energy, ventilation,hardware and furniture, tableware, medicine, electricity, packaging,construction,automobile and other industries and fields.
Q: When shipping, what kind of packing?
A: We use standard export packing.
Q: What are your delivery terms?
A: EXW, FOB, CFR, CIF.
Q: What's your delivery time?
A: Generally speaking, it takes 30 to 60 days after receiving your advance payment. The specific delivery time depends on the item and quantity of your order.
Q: Can you make it as required?
A: Yes, we can produce according to your samples or technical drawings. We can make molds and fixtures.
Q: Do you have professional engineers?
A: Yes.we have professional engineers and designers.
Q: Can you provide customzied machines?
A:Yes, we can design and manufacture according to your specific requirements.
